Multifunction semi-electric minilifter, featuring a capacity of 100 or 200 kg and a lifting height of 1500 or 2000 mm
Multifunction semi-electric minilifter NewBingo
NEWBINGO is a multifunction minilifter with manual drive and electric lifting, with aluminium mast to ensure lightness and great manoeuvrability. Featuring a capacity of 100 or 200 kg and a lifting height of 1500 or 2000 mm. Fitted with 2X12V 38Ah lead-acid batteries that require no maintenance and a 24V 6A built-in charger. Two fixed wheels and two castor wheels with brake (optional feature: four castor wheels). Different accessories are available to complete the machine (see table in the ACCESSORIES section)
Model | u.m | NEWBINGO 100 | NEWBINGO 100.2 | NEWBINGO 200 | NEWBINGO 200.2 |
Capacity | kg | 100 | 100 | 200 | 200 fino a 1500 mm 100da 1500a2000mm |
Lifting | mm | 1500 | 2000 | 1500 | 2000 |
Mast Height | mm | 1920 | 2420 | 1920 | 2420 |
Rollers | N/mm | 2/80x30 | 2/80x30 | 2/80x30 | 2/80x30 |
Wheels | N/mm | 2/100x30 | 2/100x30 | 2/100x30 | 2/100x30 |
Lifting motor | V/W | 24/300 | 24/300 | 24/300 | 24/300 |
Lifting speed | cm/sec | 8,3/6,0 | 8,3/6,0 | 8,3/6,0 | 8,3/6,0 |
Battery | NxV/Ah | 2x12/38 | 2x12/38 | 2x12/38 | 2x12/38 |
Charger | V/A | 24/6 | 24/6 | 24/6 | 24/6 |
Weight | kg | 100 | 112 | 100 | 110 |
